Setup Instructions¶

Cables and Accessories¶

Samsung USB Power Adapter (5V/2A)¶

You can purchase the Samsung Power Adapter (5V/2A) from us if needed:

USB 2.0 Type C Power Cable (1M)¶

The included USB power cable can be purchased from us if needed:

C14 to C13+Euro Y Type Splitter Adapter¶

When the projector is ceiling-mounted and only the projector's power cable is available, or when you want a single-cable solution from the power outlet to the display device, the question arises of how to power both the projector/screen and the EZCast Pro Dongle II simultaneously.

With a C14 to C13+Euro Y Type Splitter Adapter, you can convert the power cable into a European socket and C13 cable. This, combined with the power adapter, enables power supply for both devices. You can purchase the Y Type Splitter Adapter from us if needed.

HDMI to VGA Adapter¶

Does your display or projector not have an HDMI port but only a VGA connection? With this HDMI to VGA Adapter, you can use the EZCast Pro Dongle II with older display devices.

For stable signal transmission and audio playback, connect a micro-USB power supply. Audio is transmitted via a 3.5mm audio cable.

HDMI Extension Cable (1M)¶

An HDMI extension cable can help avoid signal interference with large displays. You can purchase this from us if needed:
